• 409.6 kHz sampling frequency
• Class A according to IEC 61000-4-30 Ed.3
• 8 GB memory (can be increased up to 32 GB)
• Built-in battery that allows 4 hours of measurement in case of supply voltage interruption
• IP 65 protection class
• Analogue and digital input
• Freely adjustable recording interval from 20 ms to 30 minutes
• Registration of basic electrical parameters
• Current and voltage up to 50th harmonic component maximum minimum and average value recording
• Recording of suprahormanics up to 170 kHz
• Total harmonic distortion record for voltage and current

• Recording of intermediate harmonic values ​​for voltage and current
• Recording of voltage and current harmonics between 2-9 kHz
• Flicker recording
• 10 ms RMS and oscilloscope event recording
• Manual, current and voltage RMS value, phase shift, envelope, periodic event trigger for event recording
• Free WiNPQ mobile evaluation software
• Evaluation of voltage quality events according to EN50160 and IEC-61000-2-2 / 2-4 standards
• Optional Wifi
• PQ-Box application developed for Android and iOS

Carrying Case

• Carrying Case

Temperature Sensor

• Temperature Sensor
• Temperature Sensor

Rogowskicoil

• 111.7085
• 111.7046
• 111.7036
• 111.7030
• 111.7023
• 111.7022
• 111.7013
• 111.7011
• 111.7006
• 111.7001

Protective Hoods

• Protective Hoods
• Protective Hoods
• Protective Hoods
• Protective Hoods

Mini Current Clamp

• Mini Current Clamp

Gps Clock

• Gps Clock

Other Accessories

• Other Accessories
